Chroma 63209
DC Electronic Load, 15600W, 1000A, 80V

Download Product Datasheet

Product Overview

RENT CHROMA 63209 Programmable DC Electronic Load

    The high power rating, parallel and synchronization capabilities make the Chroma 63209 DC electronic load especially well-suited for high power applications such as switch-mode rectifiers and for discharging batteries packs and fuel cells. With front LCD displays and rotary knob, the Chroma 63209 loads offer versatile bench top operation. Complex waveforms can also be created by driving the loads from an analog programming source.

    The Chroma 63209 programmable DC loads provide constant current, constant resistance, constant voltage and constant power modes. For low voltage/high current applications, the Chroma 63209 electronic DC load is available with a low voltage mode, which provides ultra-low voltage operation and in many cases can compensate for large voltage loss in the input wiring. A current closed loop design connecting all power MOSFET devices in parallel insures high accuracy load control with minimal drift (less than 0.15% of the current setting).  The load can short a DC power source or any power supply that has a built in current limit function and measure its short circuit current so that users can verify if the UUT current limit is functional.

Specifications for the Chroma 63209 High Power DC Electronic load include:

See Datasheet for full specifications

Other models is this series are 63201, 63202, 63203, 63204, 63205, 63206, 63207, 63208, 63210, 63211, 63212.
