Chroma 61705
AC Source 300V DC, 15 - 1.2kHz, 12kVA, 3 Phase

Power Supplies >> AC Power Sources, More than 10kVA >> AC Source 300V DC, 15 - 1.2kHz, 12kVA, 3 Phase
Rent Used Test Equipment
Manufacturer: Chroma
Model: 61705

Chroma 61705 AC Source 300V DC, 15 - 1.2kHz, 12kVA, 3 Phase

Electronic Test and Measurement Equipment

Chroma 61705 AC Source 300V DC, 15 - 1.2kHz, 12kVA, 3 Phase Product Datasheet Download Product Datasheet

Rent Test Equipment

Available Option Configurations

Config-01

  • A615001 - GPIB/RS232 Interface
  • Available for Rental    GET QUOTE

Product Overview

RENT Chroma 61705 AC Power Source (Call for availability)



    The Chroma 61705 Programmable AC source delivers pure, 5-wire, 3-phase AC power. It supplies the output voltage from 0 to 300VAC and it can be set individually for each phase. Users also can set the phase angle from 0° to 360°.  Because of the wide output frequency from 15 to 1200Hz, it is suitable for avionics and military applications. The 61705 AC power source uses the state-of-the-art PWM technology and power factor correction circuit, so it is capable to generate very clean AC output with typical distortion less than 0.3%.

    By using advanced DSP technology, the 61705 AC source offers precision and high speed measurements such as RMS voltage, RMS current, true power, power factor, and current crest factor. Users can easily program variant waveform for immunity tests.  These kinds of function make the 61705 able to simulate unbalanced 3-phase power. The self-diagnosis routine and protections against over power, over current, over voltage, over temperature and fan fail, the Chroma 61705 AC power sources ensure the quality and reliability for even the most demanding engineering testing and production line application.



Specifications of the Chroma 61705 AC Power Source includes:

AC Power 12kVA (4kVA per phase)
Voltage Low/High 0-150V/0-300V
Frequency DC, 15-1500Hz
Max Current Single/3-Phase 192A/96A
Power Factor 0 to unity



See Datasheet for Full Specifications
