Agilent N5245A, Keysight N5245A, HP N5245A
PNA-X Network Analyzer, 10 MHz to 50 GHz

Network Analyzers >> More than 40 GHz >> PNA-X Network Analyzer, 10 MHz to 50 GHz
Rent Used Test Equipment
Manufacturer: Keysight / Agilent / HP
Model: N5245A

Keysight / Agilent N5245A PNA-X Network Analyzer, 10 MHz to 50 GHz 2 Keysight / Agilent N5245A PNA-X Network Analyzer, 10 MHz to 50 GHz 3 Keysight / Agilent N5245A PNA-X Network Analyzer, 10 MHz to 50 GHz Video CLICK TO ENLARGE Keysight / Agilent N5245A PNA-X Network Analyzer, 10 MHz to 50 GHz

Electronic Test and Measurement Equipment

Keysight / Agilent N5245A PNA-X Network Analyzer, 10 MHz to 50 GHz Product Datasheet Download Product Datasheet

Rent Test Equipment

Product Overview

RENT KEYSIGHT N5245A (Agilent) (call for availability)

The Keysight N5245A Network Analyzer provides a wide range of measurement applications for amplifiers, converters, antennas, or mixers with a single connection. The Keysight N5245A also offers configurability with a built-in second source, combiner, and internal signal-routing switches.

The Keysight N5245A PNA-X Network Analyzer allows users to replace racks and stacks with a single instrument. With a combination of two internal signal sources, a signal combiner, S-parameter Test Set and noise receivers, pulse modulators and signal generators, and a flexible set of switches and RF access points, the Keysight N5245A PNA-X Network Analyzer provides a powerful hardware core for a broad range of linear and nonlinear measurements, all with a single set of connections to your device-under-test (DUT).

Others features and specifications of the Keysight N5245A (Agilent) Network Analyzer include:

  • 10 MHz to 50 GHz
  • 2- or 4-ports with two built-in sources
  • 121 to 125 dB system synamic range and 133 to 137 direct receiver dynamic range (depends on configuration)
  • High output power 13 dBm (+16 dBm optional),
  • Low harmonics (-60 dBc) and a wide power sweep range
  • Trace Noise: 0.002 dBrms
  • Noise Floor: -111 dBm
  • Best Speed at 201 Point, 1 Sweep: 4.4ms
  • Best dynamic accuracy
  • Low noise floor of -111 dBm



Click to see all Keysight / Agilent PNA-X network anlyzers
