Rent or Buy Solmetric PVA-1500S 1500V PV Analyzer I-V Curve Tracer

Tektronix Encore

Solmetric PVA-1500S
1500V PV Analyzer I-V Curve Tracer

Electrical Test and Power Analyzers >> Photovoltaic Analyzers and Testers (PV) >> 1500V PV Analyzer I-V Curve Tracer
Rent Used Test Equipment
Manufacturer: Solmetric
Model: PVA-1500S

Solmetric PVA-1500S 1500V PV Analyzer I-V Curve Tracer

Electronic Test and Measurement Equipment

Solmetric PVA-1500S 1500V PV Analyzer I-V Curve Tracer Product Datasheet Download Product Datasheet

Rent Test Equipment

Available Option Configurations


  • V2 - Enhanced Version
  • MSRP: $9,895 | In Stock!    GET QUOTE


  • V3 - Enhanced Version + Extended Battery Life
  • MSRP: $9,895 | Available for Rental    GET QUOTE

Product Overview

RENT SOLMETRIC PVA1500S PV Analyzer I-V Curve Tracer (Call for Availability)


The Solmetric PVA-1500S PV Analyzer Kit is a 1500 volt I-V curve tracer with built-in PV performance modeling and advanced wireless irradiance, temperature and tilt sensing. It provides unprecedented measurement throughput and accuracy and delivers deep insight into the performance of your arrays. For each string, the PV Analyzer measures the I-V (current vs. voltage) and P-V (power vs. voltage) curves with a single button click. The measured results are compared to the expected performance, taking into account the irradiance and module cell temperature at the time of the I-V measurement.

The Solmetric PV Analyzer is designed to work as hard as you do. High measurement throughput means it can measure 1 MW in less than 2 hours--even in hot environments where other curve tracers shut down. The I-V Unit communicates wirelessly to your Windows tablet or laptop (not included), enhancing safety and allowing freedom of movement during testing. Automated data analysis and reporting save you time. The incident angle corrected SolSensor is able to make accurate irradiance readings in lower light conditions extending your working window.


Specifications for the SOLMETRIC PVA1500S PV Analyzer I-V Curve Tracer Include:

PV Voltage Range 0 - 1500V
Current Range 0 - 30A

I-V Sweep Duration

0.05 - 2s, 0.2 typical for strings
I-V Trace Points 100 or 500, user selectable

See Datasheet for full specifications
